DESCRIPTION

Basic Info

Model NO.	T1800FZ-PL
Turntable Size	D=1800mm, H From 490mm
Wrapping Size	500-1100mm X 500-1100mm
Control System	PLC
Film Shelf System	Pre-Stretching Turntable
Transport Package	Iron Frame + Wooden Box
Specification	3000*2000*2650-3650mm
Trademark	SINOLION
Origin	Shandong
HS Code	84224000
Production Capacity	80sets/Month

Product Description

Advanced Intelligent Online Fully Automatic pallet stretch wrapping machine

(Subject to your demands.)

Product Description

Specification
Product name	Advanced Intelligent Online Fully Automatic pallet stretch wrapping machine
Model	T1800FZ-PL stretch wrapping machine
Wrapping size	500-1100mm(L) x 500-1100mm(W)
Wrapping height	Max.2400mm (1800mm/2800mm available)
Package	1) Inner: Iron frame
	2) Outer: wooden box
	P.S: Customized packages are also welcome
Turntable size	Dia:1800mm Height: from 490mm
Turntable bearing	Max. 2000kgs
Turntable speed	0~15RPM (turntable transducer adjust, steady stop and start)
Machine weight	700kg
Machine dimension	3000*2000*2650-3650mm
Control system	PLC control, top & bottom wrapping circle 1-20 adjustable; auto high sense; auto turntable reset
Work efficiency	20-40 loads/H
Film carriage system	Driven pre-stretch carriage, stretch ratio up to 300%
Tower	Double chain design. Lifting speed adjustable.
Electric	AC380V/50Hz 3phase
Power	Turntable 0.75kw, film carriage 0.35kw, tower 0.37kw, conveyor 0.55kw

Certifications

Company Profile

2017.3 Shandong Sinolion Machienry Corp. Ltd start expanding the new plant.

2015.9 Shandong Sinolion Machinery Corp. Ltd was officially listed in the stock transfer system, stock code: 833475.

2015.4 Shandong Sinolion Machinery officially changed its name to "Shandong Sinolion Machinery Corp. Ltd".

2014.12 "Sinolion Machienry and Sinolion", the trademark was identified as Shandong famous brand.

2013.12 "Sinolion Machienry and Sinolion" were appraised as Jinan famous brand.

2010.8 Moved to the high-tech zones in No. 2010 Kehang Road, High-tech Zone, Jinan City, Shandong.

2007 Land compensation in the development zone Suncun, plan and construct new production plant. And It had constructed in September, 2009.

2006.8 Shandong Sinolion Machinery Corp. Ltd has been formally established.
